AVer CL01

AVer CL01

RM7,857.00

Specs

  • I/O Interface

  • Communication
    • RS-485, RS-422, RS-232, IP, Micro USB for firmware upgrades
  • Baud Rate
    • 2400, 4800, 9600, 19200, 38400 bps
  • User Interface

  • Display
    • OLED display screen
  • Camera Shortcut Channel
    • 7
  • Rotation Button
    • 3
  • Joystick
    • 1
  • Camera Control

  • IP Address
    • Default: 192.168.1.162 /163 /164 /165 /166 /167 /168 (from Cam 1 to Cam 7)
  • UDP Port
    • 08090
  • Cam ID
    • 1 to 7 and more (255* max.)
  • Control Protocol
    • VISCA, SONY VISCA , Pelco D/P, UDP, IP (VISCA over IP)
  • System

  • Operating Temperature
    • 0°C ~ 40°C (32°F ~ 104°F)
  • Dimensions
    • 173 mm (W) x 99 mm (H) x 350 mm (D)
  • Net Weight
    • 2.5 kg
  • Power Source
    • DC 12V/2A
    • AC 100 – 240V
  • Power Consumption
    • 24 W
  • Application
    • Indoor
  • Warranty
    • 3 years
  • Package Content
    • User manual
    • 4-pin RS485 terminal
    • power adapter

Out of stock

Compare
SKU: CL01 Category:

Share this product

Hardware Appearance

1Rotation Button

2Joystick

3OLED display screen

1Micro USB

2RS-422

3RS-232

4RJ45

5DC 12V

Specs

  • I/O Interface

  • Communication
    • RS-485, RS-422, RS-232, IP, Micro USB for firmware upgrades
  • Baud Rate
    • 2400, 4800, 9600, 19200, 38400 bps
  • User Interface

  • Display
    • OLED display screen
  • Camera Shortcut Channel
    • 7
  • Rotation Button
    • 3
  • Joystick
    • 1
  • Camera Control

  • IP Address
    • Default: 192.168.1.162 /163 /164 /165 /166 /167 /168 (from Cam 1 to Cam 7)
  • UDP Port
    • 08090
  • Cam ID
    • 1 to 7 and more (255* max.)
  • Control Protocol
    • VISCA, SONY VISCA , Pelco D/P, UDP, IP (VISCA over IP)
  • System

  • Operating Temperature
    • 0°C ~ 40°C (32°F ~ 104°F)
  • Dimensions
    • 173 mm (W) x 99 mm (H) x 350 mm (D)
  • Net Weight
    • 2.5 kg
  • Power Source
    • DC 12V/2A
    • AC 100 – 240V
  • Power Consumption
    • 24 W
  • Application
    • Indoor
  • Warranty
    • 3 years
  • Package Content
    • User manual
    • 4-pin RS485 terminal
    • power adapter
